Steel Inner Suspended Gin Pole

Model:03601-10

As a universal solution that can tackle the most demanding vertical lifting challenges in tight or complex environments, this MARSHINE Steel Inner Suspended Gin Pole is designed by MARSHINE, a large Chinese company offer competitively priced high-quality tools, it is for telecom tower erection, substation maintenance, and industrial installations, this robust gin pole combines high-tensile steel construction with a space-saving suspended design, enabling precise load handling where traditional cranes or gin poles cannot operate.

Send Inquiry

Product Description

Steel Inner Suspended Gin Pole

Engineered for reliability and strength, this MARSHINE Steel Inner Suspended Gin Pole is suspended internally, providing a secure and stable setup for lifting conductors, insulators, crossarms, and other components during transmission line construction and maintenance. As a heavy-duty lifting tool designed for vertical lifting operations inside tubular steel or concrete poles, its rugged steel construction ensures long-lasting performance in harsh job site conditions.

1.Product Parameter

Item number	Model	Length (m)	Allowable axial load (KN)	Main materials	Auxiliary materials	Remarks
03601-10	300	10	39	50×50×5	30×30×3	Main materials: Q235
03601-12		12	27			Auxiliary materials: Q235
03601-13		13	23
03601-15		15	17.5
03602-12	400	12	51	50×50×5	30×30×3	Main materials: Q345
03602-13		13	44
03602-16		16	29
03602B-13		13	70	63×63×5	30×30×3	Auxiliary materials: Q235
03602B-16		16	57.5
03602B-18		18	45
03602B-20		20	37
03603-16	500	16	93	63×63×5	40×40×4	Main materials: Q345
03603-18		18	73.5
03603-20		20	59.5
03603-22		22	49.5
03603-24		24	41.5			Auxiliary materials: Q235
03603B-16		16	149	70×70×6	40×40×4
03603B-20		20	95.5
03603B-24		24	66.5
03603B-28		28	48.5
03604-16	600	16	221	70×70×6	40×40×4	Main materials: Q345
03604-20		20	141.5			Main materials: Q345
03604-24		24	98			Auxiliary materials: Q235
03604-28		28	72			Auxiliary materials: Q235
03605-20	700	20	294	80×80×6	40×40×4	Main materials: Q345
03605-24		24	204			Main materials: Q345
03605-28		28	150			Auxiliary materials: Q235
03605-32		32	115			Auxiliary materials: Q235
03606-24	800	24	249	80×80×7	50×50×4	Main materials: Q345
03606-28		28	227			Main materials: Q345
03606-32		32	174			Auxiliary materials: Q235
03606-36		36	137.5			Auxiliary materials: Q235

2.Product Feature

Rugged Steel Construction: The MARSHINE Steel Inner Suspended Gin Pole is made of high-strength steel to withstand heavy loads and provide exceptional durability.

Compact suspended design: The slim profile and built-in mounting system easily fit inside narrow towers or building shafts, eliminating the need for external rigging.

High Load Capacity: Designed to support large loads during lifting and installation.

Corrosion Resistant: The coated finish offers excellent resistance to rust and environmental wear.

Heavy-duty steel construction: The reinforced high-carbon steel frame provides a 6:1 safety factor and supports high working loads, making it ideal for lifting towers, transformers or industrial machinery.

Fast assembly: Pre-assembled modular components with quick-connect pins allow installation in 20 minutes, reducing downtime by 50% compared to traditional lifting poles.

3.Product Application

Lifting and installing hardware inside steel pipe or concrete transmission poles

Lifting insulators, suspension clamps, conductor bundles and tower components

Our MARSHINE Steel Inner Suspended Gin Pole can be used for high voltage transmission line construction and live line maintenance projects

Telecommunication tower installations in urban cores

4.Product Details

The MARSHINE Steel Inner Suspended Gin Pole is the perfect solution for safe and efficient internal operations on transmission poles.Here are some features:

Decades of experience: MARSHINE is a trusted global manufacturer of power line tools and lifting equipment.

Precision Engineering: Designed for safety, efficiency and ease of use in demanding environments.

Cost Effective: Durable steel construction reduces long-term maintenance costs by 40%.

Portability: Can be disassembled into compact components for easy transport to remote areas or urban sites.

Reliable Performance: Trusted by energy providers and telecom operators in more than 50 countries for 5G upgrades, power tower erection and grid modernization projects.
