Tubular Tower Mounted Gin Pole

Model:LBNX250-8

As a large scale Chinese company, our MARSHINE was specialize for the electric power industry tools, and always offered with affordable price. The MARSHINE Tubular Tower Mounted Gin Pole is a tower erecting device that designed for the efficient and safe lifting and installation operations on the tubular towers. This durable equipment was specially engineered to meet the demanding requirements of the modern infrastructure projects, can offers the excellent performance with the durability, and the adaptability.

Send Inquiry

Product Description

Being a robust yet versatile lifting system from our MARSHINE proud products that integrates seamlessly with the tubular tower structures, the Tubular Tower Mounted Gin Pole is designed to facilitate the installation of the heavy components such as the transformers, switchgears, communication equipment, and the wind turbine nacelles. Its modular design allows user for the easy assembly, disassembly, and repositioning, makes it a good choice for both the onshore and the offshore applications.

Product Parameter

Item number	Model	Length	Allowable axial load	Cross section	Weight	Remarks
Item number	Model	Length	(kn)	(mm)	(kg/m)	Remarks
3119	LBNX250-8	8	37	250	10.5	Single pulley, 2sets waist loop
3120	LBNX250-9	9	29
3121	LBNX250-10	10	23
3122	LBNX250-11	11	19
3123	LBNX250-12	12	16
3124	LBNX250-13	13	13
3125	LBNX250-14	14	11
3126	LBNX250-15	15	10
3131	LBNX300-11	11	29	300	11	Double pulley, 2sets waist loop
3132	LBNX300-12	12	24
3133	LBNX300-13	13	22
3134	LBNX300-14	14	18
3135	LBNX300-15	15	16
3136	LBNX300-16	16	13
3137	LBNX300-17	17	12
3138	LBNX300-18	18	11
3141	LBNX350-11	11	40	350	13.5	Double pulley, 2sets waist loop
3142	LBNX350-12	12	33
3143	LBNX350-13	13	30
3144	LBNX350-14	14	24
3145	LBNX350-15	15	21
3146	LBNX350-16	16	19
3147	LBNX350-17	17	17
3148	LBNX350-18	18	15
3151	LBNX400-12	12	43	400	14.6	Double pulley, 2sets waist loop
3152	LBNX400-13	13	38
3153	LBNX400-14	14	32
3154	LBNX400-15	15	28
3155	LBNX400-16	16	25
3156	LBNX400-17	17	22
3157	LBNX400-18	18	19
3158	LBNX400-19	19	16
3159	LBNX400-20	20	14

Product Feature

Built with the high-strength alloy steel and the advanced manufacturing techniques, the MARSHINE Tubular Tower Mounted Gin Pole is able to ensures the outstanding durability and the outstanding load-bearing capacity. Been equipped with the precision-balanced pulleys and the load-sensing mechanisms, this gin pole can ensures the smooth and controlled lifting operations. Can be adjusted to accommodate different tower configurations and component sizes easily, it can provides the flexibility for various projects. And coated with the advanced anti-corrosion materials, this gin pole is suitable for the use in the harsh environmental conditions, including the coastal and the industrial areas. Incorporates the anti-overload sensors, emergency braking systems, and the secure locking mechanisms, this device can ensures the operator's safety while preventing accidents.

Product Application

The MARSHINE Tubular Tower Mounted Gin Pole is widely used in installation tasks of the transformers, circuit breakers, and the other heavy equipment on power transmission towers, or for installing the antennas, repeaters, and the communication equipment on the cellular towers, and can supporting the deployment of 5G infrastructure and the broadcasting systems as well.
