Aluminum Alloy Tubular A-Shape Gin Pole with Manual Winch
Featuring a lightweight yet durable A-frame structure and an integrated manual winch system, allows operators to lift heavy loads with precision and control, even in remote or challenging field environments, this MARSHINE Aluminum Alloy Tubular A-Shape Gin Pole with Manual Winch is a versatile lifting tool designed for safe and efficient hoisting of materials during power line construction, pole erection, and equipment installation.
1.Product Parameter
| Itemnumber | Model | BaseStroke(m)/Allowableverticalload(KN) | Hoisting with manual winch | Weight(kg/m) | |||
| Maximumlength(m) | Maximum weight(kg) | ||||||
| Hoisting directly | Using bi-pulley | Using tri-pulley | |||||
| 03331 | LBGR100J-6 | 2.1/18 | 9 | 600 | 720 | 5.5 | |
| 03332 | LBGR100J-7 | 2.4/13 | 11 | 550 | 700 | ||
| 03341 | LBGR120J-6 | 2.1/30 | 9 | 550 | 1050 | 1280 | 7.5 |
| 03342 | LBGR120J-7 | 2.4/26 | 11 | 550 | 870 | 1040 | |
| 03343 | LBGR120J-8 | 2.8/21 | 13 | 700 | 840 | ||
| 03351 | LBGR150J-8 | 2.8/31 | 13 | 550 | 1100 | 1500 | 8 |
| 03352 | LBGR150J-9 | 3.1/28 | 15 | 550 | 1100 | 1500 | |
| 03353 | LBGR150J-10 | 3.5/24 | 17 | 550 | 1050 | 1280 | |
| 03354 | LBGR150J-11 | 3.8/20 | 19 | 550 | 980 | 1160 | |
2.Product Feature
High-strength aluminum alloy frame: Lightweight, easy to transport and install, yet strong enough to support heavy lifting tasks.
A-type design for greater stability: Ensures even load distribution, stable lifting performance, and reduced risk of tipping.
Integrated manual winch: Smooth and easy-to-operate winch with locking device for controlled lifting and securely holds the load.
Corrosion resistance: Anodized or specially treated surfaces provide superior protection against rust and weather.
Quick assembly and portability: Modular tubular structure can be quickly assembled and disassembled, perfect for on-site movement.
3.Product Application
Installation and maintenance of utility infrastructure
Erection of telecommunication towers in remote areas
Lifting of solar panels and wind turbine components
Our MARSHINE Aluminum Alloy Tubular A-Shape Gin Pole can be used for maintenance of utility poles and replacement of transformers
Installation of bridge cables and construction of confined spaces
Emergency recovery operations in disaster areas
4.Product Details
Combining strength, portability, and ease of use, our MARSHINE Aluminum Alloy Tubular A-Shape Gin Pole with Manual Winch is an essential tool for efficient and controlled lifting in power line construction and maintenance. Here are the details about it:
Professional Lifting Solutions: With our years of experience in the power industry, we provide high-performance tools you can trust.
Precision Manufacturing: Each lifting pole is produced to strict quality standards to ensure safety and performance.
No Power Assist Required: Manual winches do not require generators or hydraulic systems, ideal for off-grid sites.
Cost Effectiveness: The reusable design reduces equipment rental costs by 60% and has a service life 3 times that of traditional models.
Safety Compliance: Meets CE and ISO standards, equipped with overload alarm and double-locking safety pins.
Global Reliability: Trusted by telecom and energy teams in more than 50 countries for wind farm installation.
