Aluminum Inner Suspended Lattice Gin Pole

Model:LBNX500-14A

Our MARSHINE are a large Chinese company concentrate on providing the durable tower installation device with the competitive price to help the operators deal with the tasks in the demanding environments. The MARSHINE Aluminum Inner Suspended Lattice Gin Pole is suitable for lifting and positioning heavy loads in various industrial applications, particularly in power line constructions.

Send Inquiry

Product Description

Been crafted from the high-quality aluminum alloy, the MARSHINE Aluminum Inner Suspended Lattice Gin Pole is able to ensures the outstanding strength-to-weight ratio while maintaining the corrosion resistance. Its lattice structure can provides the stability and the flexibility, allowing it to handle a wide range of the lifting tasks with ease. And the "Inner Suspended" design enables the seamless integration into the existing structures, making it ideal for the use in the confined spaces or within the pre-existing frameworks.

Product Parameter

Itemnumber	Model	Length(m)	Allowable axial load(KN)	Cross section(mm)	Weight(kg/m)	Remark
03511	LBNX500-14A	14	75	500	18	Doublepulley.2sets waistloop
03512	LBNX500-15A	15	70
03513	LBNX500-16A	16	64
03514	LBNX500-17A	17	57
03515	LBNX500-18A	18	50
03516	LBNX500-19A	19	45
03517	LBNX500-20A	20	41
03518	LBNX500-21A	21	37
03519	LBNX500-22A	22	34
03521	LBNX500-17B	17	88	500	22	Doublepulley.2sets waistLoop, strengthenedtype
03522	LBNX500-18B	18	77
03523	LBNX500-19B	19	70
03524	LBNX500-20B	20	65
03525	LBNX500-21B	21	60
03526	LBNX500-22B	22	56
03527	LBNKX500-23B	23	52
03528	LBNX500-24B	24	47
03529	LBNX500-25B	25	42
03531	LBNX600-17A	17	75	600	20	Doublepulley.2sets waistloop
03532	LBNX600-18A	18	70
03533	LBNX600-19A	19	65
03534	LBNX600-20A	20	60
03535	LBNX600-21A	21	55
03536	LBNX600-22A	22	49
03537	LBNX600-23A	23	45
03538	LBNX600-24A	24	41
03539	LBNX600-25A	25	38
03541	LBNX600-17B	17	119	600	24	Doublepulley.2sets waistLoop, strengthenedtype
03542	LBNX600-18B	18	111
03543	LBNX600-19B	19	104
03544	LBNX600-20B	20	94
03545	LBNX600-21B	21	85
03546	LBNX600-22B	22	76
03547	LBNX600-23B	23	70
03548	LBNX600-24B	24	64
03549	LBNX600-25B	25	58

Product Feature

The inner suspended mechanism of our MARSHINE Aluminum Inner Suspended Lattice Gin Pole enables the height adjustments to accommodate the different project requirements, and is able to provide the flexibility in various of applications. Been made from the durable aluminum alloy, it combines the lightweight and the rust-resistance, can ensures the long-lasting performance. The lattice design can offers the enhanced stability an the excellent load-bearing capacity, make it suitable for lifting the heavy loads such as utility poles, transformers, and the communication towers. And the modular construction allows it for quick assembly and disassembly, can effectively reduce the setup time and the labor costs.

Product Application

The MARSHINE Aluminum Inner Suspended Lattice Gin Pole can be widely used in the power line constructions to lift and set the utility poles,transformers, and the other heavy electrical components, or for erecting the communication towers and installing the antennas, and is perfect for lifting beams, girders, and the other structural elements in the bridge and the building constructions as well. Further more, it is able to lift the heavy objects during the disaster recovery and the rescue missions.

Product Details

For those seeking a durable, versatile, and high-performance tool for cable laying operations, the MARSHINE Aluminum Inner Suspended Lattice Gin Pole can be a good choice for your construction teams.

Original Country:China.

Feature: Explosion-Proof.

Warranty:1year.

Condition: New.

Leading Time:30-35days.

Functions: Erecting Tower.

Transport Package: Carton Box.

Certification: CE, ISO9001.

Payment Terms: T/T, L/C, Paypal.
