Portable Electrical Cable Pulling Winch Machine

As a company working on exploring and manufacturing portable electrical cable pulling winch machine from China, we supply good price products, and in the same time, with full series and high technology and reliable quality, MARSHINE has received a good reputation among the same industry at home and abroad. We always adhere to the philosophy "quality first, users first", and continues to promote the "integrity, development, and innovation" entrepreneurial spirit, for the prosperity and development of power industry.

Send Inquiry

Product Description

The MARSHINE Portable Electrical Cable Pulling Winch Machine is usually used for line construction to erect towers and perform sagging operations. When using 380V AC power, a grounding device is required for safe use. However, it is not suitable for use on rainy days.

Product Parameter

Item number		09121D	09123D
Motor		Y100L-2	112M-2
Power(kW)		3	4
Speed(rpm)		2880	2890
Pull force(kn) / Speed(m/min)	Quick	10/15.3	15/12.3
	Moderate	15/6.1	30/4.9
	Slow	30/3.9	50/3.1
	Reverse	-/4.4	-/3.5
Drum bottom of groove diameter(mm)		Φ160	Φ160
Dimensions(mm)		810550510	830550510
Weight(kg)		122	140

Product Feature

Electric cable pulling winch machine is a mechanical device that uses an electric motor as a power source. Here are some of the main product features of electric winches:

Stable power supply: Electric cable pulling winches rely on electricity to drive and provide stable and continuous power output.

High-power motor: Equipped with a high-power motor, it can provide strong traction and is suitable for towing heavy objects.

High-strength steel cable: The use of high-strength steel cable ensures safe and reliable operation under high load conditions.

Sturdy structure: Durable materials and designs can be used for extended periods of time in harsh working environments.

Anti-corrosion treatment: The surface has undergone anti-corrosion treatment and is suitable for humid or dusty environments.

Multiple protection mechanisms: Equipped with safety devices to ensure safety during operation, such as the overload protection and braking system.

Easy to replace parts: Key components are designed to be easy to replace, reducing maintenance time and cost.

Zero Emission: The electric cable winch does not produce exhaust gas during operation, which is environmentally friendly.

Low Noise: The motor operates with low noise, reducing interference with the surrounding environment.

Low Operating Cost: The operating cost of the electric cable winch is relatively low, especially in areas with sufficient electricity supply.

Long Life: The motor and high-strength steel cable have a long service life, reducing the cost of frequent equipment replacement.

Product Application

Our MARSHINE electric cable pulling winch machine is suitable for tower drooping operations in line construction. Here are some of the main application scenarios of electric cable pulling winch machines:

On construction sites, electric cable pulling winches are often used to lift heavy objects such as building materials, steel bars and concrete.

Since construction sites often lack electricity supply, electric cable pulling winches are particularly important due to their independent power supply.

They can help workers transport materials from the ground to high-rise buildings, or haul heavy equipment during foundation excavation.
