Hydraulic Cable Puller 10T

Model:SA-YQ180

Dedicated to manufacturing excellent Hydraulic Cable Puller 10T at competitive prices, MARSHINE, a company based in China, focuses on producing high-standard and high-quality international products and has established trade relations with over 50 countries worldwide. With many years of deep involvement in the power machinery industry, we are undoubtedly an excellent choice for you.

Send Inquiry

Product Description

As a robust cable pulling machine, our MARSHINE Hydraulic Cable Puller 10T is designed to deliver the excellent pulling force and the operational efficiency for the electricians and linemen working in the cable installation projects. Engineered to handle the tough cable installation and tensioning tasks with the precision and the reliability, this winch machine is able to offers a maximum pulling force of 18 tons. It is capable of managing the large-diameter cables, bundle conductors, and the other heavy-duty applications due to its sturdy construction and the outstanding functionality.

Product Parameter

Model	SA-YQ180
Item Number	07051
Maximum Pull Force(KN)	180
Continuous Pull Force(KN)	150
Maximum Speed(km/h)	5
Bull wheel bottom of groove diameter(mm)	Φ760
Bull wheel grooves number	10
Maximum suitable steel rope diameter(mm)	Φ30
Maximum through connector diameter(mm)	Φ75
Engine power/speed(kw/rpm)	223.5/2100
Dimensions(mm)	578023502820
Weight(kg)	8000

Product Feature

Combing the efficiency with the reliability, the MARSHINE Hydraulic Cable Puller 10T is a powerful winch machine that owns the high-power motor to ensures the smooth yet continuous operations. Been constructed from the high-strength alloy steel and treated with the anti-corrosion coatings, this machine is built to withstand the harsh outdoor environments and ensures its last long durability. And due to its adjustable speed control, this machine allows the users to regulate the pulling speed according to the specific requirements of the tasks, so that to ensures the precise and controlled performance.

Product Application

The MARSHINE Hydraulic Cable Puller 10T can be used to install the high-voltage power lines, bundle conductors, and the overhead cables, and is suitable for deploying the fiber-optic cables, coaxial cables, and the other communication lines, or to be applied in the installation of cables for lighting, security systems, and the elevator wiring in large-scale utility projects. Further more, it is perfect for connecting the turbines and panels to the grid in the wind farms and solar power plants.
