Heavy-Duty Hydraulic Cable Puller 40T

Model:SA-YQ420

Being Chinese company who contribute to produce high-quality, multi-function, and high-tensile devices with affordable price, our MARSHINE Heavy-Duty Hydraulic Cable Puller 40T can be a ultimate choice for electric construction. They are designed to handle heavy-duty cable constructions with ease.

Send Inquiry

Product Description

As a machine specialized for the infrastructure projects, this MARSHINE Heavy-Duty Hydraulic Cable Puller 40T is able to to handle the heavy-duty cable and conductor installations much easier then other hydraulic pullers, this powerful machine is able to delivers the 40 tons (400 KN) of hydraulic force, and empowering the contractors to tackle the cross-continental power grids, sub-sea energy interconnects, and the Arctic pipeline projects with ease.

Product Parameter

Model	SA-YQ420
Maximum pull force (kn)	420
Continuous pull force (kn)	350
Maximum speed(km/h)	5
Bull wheel bottom of groove diameter(mm)	Φ960
Bull wheel grooves number	11
Maximum suitable steel rope diameter(mm)	Φ45
Engine power/speed(kW/rpm)	402/2100
Dimensions(mm)	610026002800
Weight(kg)	14800

Product Feature

The MARSHINE Heavy-Duty Hydraulic Cable Puller 40T are forged from the oil-painted low carbon alloy steel, is able to withstand the harsh construction conditions. With its outstanding pulling force for the heaviest cables (up to 4,000 mm² copper/aluminum), make it suitable for the ultra-high-voltage transmission lines, offshore wind farm export cables, and other construction operations. The triple-layer drum can stores the large amount of steel wire or synthetic rope, can effectively reduce the downtime on the transcontinental or transoceanic projects.

Product Application

Our MARSHINE Heavy-Duty Hydraulic Cable Puller 40T can be used to install the ultra-high-voltage overhead lines across the continents or the sub-sea cables linking nations. It is also able to deal with the deployment of the high-voltage cables for the offshore wind farms in the hurricane-prone zones.Meanwhile, it is suitable for powering the megacity metro expansions, transcontinental rail networks, or the hyper scale data center hubs.
