Been built for utility giants, renewable energy developers, and heavy industrial contractors, the MARSHINE Line Stringing Hydraulic Cable Puller 25T sets a new benchmark in large-scale cable and conductor installations. Designed to tackle the most formidable challenges, this machine combines brute-force hydraulic capacity with intelligent automation, delivering flawless performance for underground, aerial, and subsea projects under extreme loads of up to 25 tons (250 KN).
Product Parameter
| Model | SA-YQ250 |
| Maximum pull force (kn) | 250 |
| Continuous pull force (kn) | 200 |
| Maximum speed(km/h) | 5 |
| Bull wheel bottom of groove diameter(mm) | Φ820 |
| Bull wheel grooves number | 10 |
| Maximum suitable steel rope diameter(mm) | Φ32 |
| Maximum through connector diameter(mm) | Φ80 |
| Engine power/speed(kW/rpm) | 261/2100 |
| Dimensions(mm) | 5750*2350*2750 |
| Weight(kg) | 9000 |
Product Feature
Our MARSHINE Line Stringing Hydraulic Cable Puller 25T owns powerful hydraulic system which can generates the colossal pulling force for the heavy duty cables (up to 2,500 mm²copper/aluminum), make it suitable for the high-voltage transmission lines, offshore wind farm interconnects, and the subsea pipelines. Its reinforced alloy steel frame with the anti-corrosion coating can help this machine to withstands the harsh environment conditions. And with the dual overload protection, emergency braking, and anti-reverse locks, this machine can protect the operator's personal safety well.
Product Application
Our MARSHINE Line Stringing Hydraulic Cable Puller 25T is suitable for deploying the subsea export cables in the deep-water projects. And can be used to install the high-voltage overhead lines or the underground cables across the rugged terrain, or to pull the heavy duty cables or the pipelines in the harsh environments. In addition, it can be used on the metro electrification, tunnel boring machine (TBM) cable feeds, and the urban grid upgrades.
Product Details
As a machine that suitable for the heavy-duty tasks, our MARSHINE Line Stringing Hydraulic Cable Puller 25T can be a good partner for the cable installation constructions.
Place Of Origin:Zhejiang,China.
Lead Time:30-35days.
Certifications:CE,ISO9001.
Warranty:1year.
