Manufactured from premium galvanized steel wire, this MARSHINE RB Type Tubular Open Ended Galvanized Cable Pulling Grips is able to provide exceptional tensile strength, flexibility, and durability while maintaining a firm grip on the cable surface. The woven mesh construction automatically tightens under tension, distributing pulling forces evenly around the cable to reduce localized stress and minimize the risk of cable damage. Available in a wide range of sizes to accommodate different cable diameters, the grips are an ideal solution for utility contractors, telecommunications installers, electrical engineers, and industrial maintenance professionals requiring safe and efficient cable replacement equipment.
| Model | Applicable Cable Diameter (mm) | Lattice Weave | Lattice Length (mm) | Overall Length (mm) | Breaking Load (Kg) |
| MAR-OE6-13 | 6-13 | Single | 230 | 305 | 760 |
| MAR-OE13-19 | 13-19 | Single | 355 | 430 | 1015 |
| MAR-OE19-25 | 19-25 | Single | 405 | 510 | 2540 |
| MAR-OE25-38 | 25-38 | Single | 455 | 610 | 3555 |
| MAR-OE38-50 | 38-50 | Double | 535 | 735 | 5080 |
| MAR-OE50-63 | 50-63 | Double | 610 | 865 | 5080 |
| MAR-OE63-89 | 63-89 | Double | 685 | 990 | 6095 |
| MAR-OE89-115 | 89-115 | Double | 685 | 990 | 7110 |
| MAR-OE115-140 | 115-140 | Double | 685 | 990 | 7110 |
Open Ended Tubular Design
The unique open ended construction enables two cables to be joined together quickly, making the grip particularly suitable for replacing existing cables with new ones during pulling operations.
High-Strength Galvanized Steel Construction
Manufactured from premium galvanized steel wire rope, the grip offers excellent tensile strength, abrasion resistance, and long-lasting durability while providing outstanding protection against corrosion.
Automatic Self-Tightening Grip
The braided tubular structure contracts naturally as pulling tension increases, creating a secure, evenly distributed grip without requiring complex locking mechanisms.
Even Load Distribution
The woven mesh design of our MARSHINE RB Type Tubular Open Ended Galvanized Cable Pulling Grips can spreads the pulling force over a large contact area, reducing concentrated stress on the cable jacket and helping protect insulation during installation.
Wide Cable Size Compatibility
Available in multiple diameter ranges, the RB style accommodates various power cables, communication cables, fiber optic cables, and other cylindrical products used in utility construction.
Reusable Design
Constructed for repeated professional use, the cable pulling grip can be reused following proper inspection, providing an economical solution for ongoing installation and maintenance work.
Flexible and Easy to Install
The lightweight tubular construction allows quick installation and removal, reducing preparation time and improving overall job-site efficiency.
Reliable Pulling Performance
Designed for demanding cable installation environments, the grip maintains stable holding power throughout the pulling process, supporting smooth cable movement over long distances.
The MARSHINE RB Type Tubular Open Ended Galvanized Cable Pulling Grips are widely used in:
Underground cable installation;
High-voltage transmission cable pulling;
Distribution network construction;
Utility maintenance and upgrading;
Industrial cable routing;
Pipeline and conduit cable pulling;
General cable handling and pulling operations.
Brand:MARSHINE.
Condition:New.
Lead Time:15-20days.
Warranty:1 year.
Certification:ISO9001.
Place Of Origin:Ningbo,Zhejiang.
Payment Term:T/T.
MOQ:50pcs.
