The MARSHINE Diesel Traction Pulling Machine Puller Tractor Four Wheel Drive is a purpose-built line construction vehicle developed to support conductor installation, cable deployment, and rope pulling operations in demanding utility projects. Combining a powerful diesel propulsion system with a high-capacity traction mechanism, this machine is engineered to deliver dependable pulling performance across a wide range of construction environments. With its compact dimensions, durable construction, and efficient powertrain, the MARSHINE pulling tractor offers a practical solution for contractors seeking a mobile and productive pulling platform for utility installation work.
| Model | SX4-VI, Four Wheel Drive |
| Max. Pulling | 100 KN |
| Traction Speed | 7-70 M/min |
| Power | 36.8 KW |
| Engine Speed | 2400 rpm |
| Dimension (L x W x H) | 3800*1800*1780 mm |
| Weight | 2200 kg |
| Note: Please check the hydraulic oil before use and change the hydraulic oil regularly | |
High-Efficiency Traction Output
Capable of generating up to 100 kN of pulling force, the machine is suitable for handling substantial installation loads associated with conductor stringing, pilot rope deployment, and cable pulling tasks.
Wide Operating Speed Range
The adjustable traction speed of 7-70 m/min enables smooth operation across different stages of a project, from careful positioning to faster line installation activities.
Robust Diesel Power Source
A 36.8 kW diesel engine operating at 2400 rpm supplies the machine with consistent power, ensuring reliable performance during prolonged construction operations.
Four-Wheel-Drive Mobility
The drivetrain is designed to maximize traction and machine control, allowing the tractor to travel efficiently through soft ground, construction tracks, sloped terrain, and other challenging site conditions.
Compact Working Footprint
Measuring 3800 mm in length, 1800 mm in width, and 1780 mm in height, the machine can be transported and positioned conveniently while still providing substantial pulling capability.
Stable Load Handling
The 2200 kg machine weight contributes to improved balance and operational steadiness when performing heavy pulling work, enhancing both safety and performance.
Field-Oriented Design
Built specifically for outdoor utility applications, the MARSHINE Diesel Traction Pulling Machine Puller Tractor Four Wheel Drive incorporates durable mechanical components capable of withstanding continuous operation in harsh environments.
Reduced Labor Requirements
The mechanized pulling system helps minimize manual effort, accelerate installation schedules, and improve overall construction productivity.
The MARSHINE Diesel Traction Pulling Machine Puller Tractor Four Wheel Drive is widely utilized for:
Transmission conductor erection;
Distribution line installation;
Ground wire deployment;
OPGW construction projects;
ADSS cable stringing;
Underground cable pulling operations;
Utility network expansion;
Renewable energy transmission projects;
Rural electrification programs;
Infrastructure construction and maintenance.
Brand:MARSHINE.
Condition:New.
Lead Time:2Months.
Warranty:1 year.
Certification:ISO9001.
Place Of Origin:Ningbo,Zhejiang.
Payment Term:T/T.
