Three-Purpose Wire Stringing Block

Model:SHCS-2

As a revolutionary tool designed by MARSHINE, a large Chinese power industry tool manufacturer, this innovative block: the MARSHINE Three-purpose Wire Stringing Block integrates stringing, alignment and tension control functions, significantly reducing equipment requirements and labor costs. It is ideal for utility professionals and contractors, with a competitive price while excelling in complex grid projects where efficiency, safety and adaptability are critical.

Send Inquiry

Product Description

Designed to support three different applications—straight-line stringing, corner stringing, and ground wire stringing, the MARSHINE Three-Purpose Wire Stringing Block is a multifunctional, high-efficiency stringing tool engineered for versatility in overhead line construction. This block adapts to various job site conditions with ease. Its innovative design allows for seamless transitions between applications, making it an essential solution for linemen working across diverse terrains and complex cable routes.

Product Parameter

Item number	Rated load(KN)	Breaking load(KN)	Applicable conductor	Weight(kg)	Remark
10291	20	40	≤ACSR240	4.35	Aluminum sheave
10292	20	40	≤ACSR240	4.0	Nylon sheave

Product Feature

This MARSHINE Three-purpose Wire Stringing Block can be used as a straight pulley, angle pulley, or the ground pulley while no need for the multiple tools. Been made of the heavy-duty galvanized steel, it can provide the outstanding strength and durability, and can withstand the outdoor environments corrosion. And the pulleys are made of the wear-resistant aluminum alloy or the durable nylon, can offer user with the low-friction cable movement and extend its service life. With the quick-release and adjustable design, this block allows the users to efficiently deal with the tasks and reduce the labor costs. The precision grooves and the smooth rotation design can protect the wires from the stress, wear, and deformation during the cable pulling operations.

Product Application

Our MARSHINE Three-purpose Wire Stringing Block is perfect for the projects that requires the flexibility and the fast adaptation to deal with the different stringing conditions. It is also suitable for all phases of conductor installation including straight, angled, and ground wire stringing. And is equally effective in the compact urban grids and the expansive rural transmission corridors to handle the pulling operations.
