As a dependable straight line messenger supporting tool that for the robust overhead lien installation which uses the insulated messenger wires, our MARSHINE Messenger Suspension Clamp SO65-95 is able to provide the secure support for messenger conductors, so that to ensure the reliable performance in the distribution networks. With a substantial breaking strength, it balances the compactness and the mechanical resilience, and make it a preferred choice for the utility line workers.
|
Model |
SO65-95 |
|
Messenger diameter |
7-16.5mm |
|
Messenger conductor size |
25-95mm2 |
|
SMFL |
22 KN |
|
ETIM Class |
EC003516 |
|
Weight |
0.5kg |
22KN safe maximum failure load can provides a strong suspension capacity to ensure the reliable performance under the mechanical stress.
Compatible with messenger wires ranging from 25 to 95 mm2, makes this MARSHINE Messenger Suspension Clamp SO65-95 suitable for various of cable cross-sections.
Designed for the messenger diameters between 7 to 16.5mm, can offer the users with the flexibility in conductor choice.
With approx 0.5kg light weight, makes it easy to handle and transport.
Streamlined design allows for quick assembly and maintenance, can effectively reduce the labor efforts.
Our Messenger Suspension Clamp SO65-95 is perfect for suspending the insulated messenger wires in the overhead power line constructions.
Ideal for the long and straight conductor spans where the stability and the continuous support is essential.
Can also be used at the 90° angles to protect the cables well.
Suitable for the system upgrades or repairing works where existing the messenger support infrastructure needs the reinforcement or replacement works.
Brand:MARSHINE.
Condition:New.
Lead Time:15-20days.
Warranty:1 year.
Certification:ISO9001.
Place Of Origin:Ningbo,Zhejiang.
Payment Term:T/T.
MOQ:50pcs.
