Ease Use Diesel Cable Winch Machine

Model:JJC-30

As a Chinese company produce tools for utility crews, renewable energy teams and industrial contractors with competitive price, MARSHINE want to show the MARSHINE Ease Use Diesel Cable Winch Machine, which redefines the efficiency of heavy-duty cable pulling with its rugged diesel power and intuitive design.

Send Inquiry

Product Description

Designed for use in remote or off-grid environments, the MARSHINE Ease Use Diesel Cable Winch Machine combines powerful performance with user-friendly operation to ensure seamless installation of power grids, telecom networks and renewable energy projects - whatever the terrain.

Product Parameter

Item Number		09111
Model		JJC-30
Power(hp)		4
Engine Model		Z170F
Speed(rpm)		2600
Pull Force(KN)/ Speed(m/min)	Quick	7/18.1
	Moderate	15/7.2
	Slow	30/4.6
	Reverse	-/5.2
Drum bottom of groove diameter(mm)		Φ160
Dimension(mm)		800620520
Weight(kg)		137

Product Feature

The high-torque diesel motor can delivers up to 5 ton pulling capacity, made the MARSHINE Ease Use Diesel Cable Winch Machine suitable for the heavy cables in the off-grid or the harsh environments. And the advanced combustion technology can reduces the diesel consumption by 20% compared to the conventional models, so that to reduce the operational costs. Equipped with the one-touch ignition to provide users with the simplified controls, can effectively improve the construction efficiency. Its heavy-duty chassis with a tow hitch enables the easy transport across the rough construction sites, deserts, or the muddy fields. With the high-tensile low carbon alloy steel frame and the protective coating that treated with the oil-paint, this winch machine is able to withstand the working temperatures from -30°C to +50°C.

Product Application

The MARSHINE Ease Use Diesel Cable Winch Machine can deploying the high-voltage cables in off-grid regions, and to pull the inter-array cables in the solar farms or the mountainous wind projects, or to install the fiber-optic lines in the remote or rugged terrain.
