The MARSHINE Model DJ Electric Winch is designed to provide unrivalled performance in the most challenging environments. Designed for industrial use, this rugged winch is rugged enough to handle heavy lifting and pulling tasks with ease.
Product Parameter
| Item number | 21126 | 21127 | 21128 | 21129 | |
| Name | Electric winch | Dual-drum electric winch | Multi-function electric winch | Tower dual-purpose electric winch | |
| Model | DJ10 | DJS10 | DJD10 | DJGT10 | |
| Pull force (KN) | 12.8 | 12.8 | 6.5 | 10 | 10 |
| Pull Speed (m/min) | 7 | 7 | 14 | 7 | 7 |
| Bottom of groove diameter (mm) | Φ128 | Φ128 | Φ256 | Φ128 | Φ128 |
| Maximum steel rope diameter (mm) | Φ10 steel rope | Φ10 steel rope | Φ18 fiber rope | Φ14 fiber rope /Φ10 steel rope | Φ10 steel rope |
| Supply Voltage(V) | AC380 | ||||
| Power (kw) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| Dimension (mm) | 820x420x400 | 820x420x400 | 820x600x1200 | 820x420x400 | |
| Weight (kg) | 79 | 90 | 126 | 104 | |
Product Feature
Powerful Motor: The MARSHINE Model DJ Electric Winch is equipped with a powerful motor that provides stable torque for heavy-duty cable pulling.
Durable Construction: High-strength steel frame ensures long service life and withstand harsh construction site environments.
Smooth Operation: Features stable speed regulation and automatic braking for increased operational safety.
Compact and Portable: Easy to transport and install, designed for a variety of terrain conditions.
Low Maintenance: Easy maintenance with minimal downtime, reducing operating costs.
Product Application
Very suitable for the installation of overhead wires, especially ACSR and OPGW cables.
This MARSHINE Model DJ Electric Winch can be used for pole tower erection, wire tensioning and mechanical lifting operations.
Commonly used in power transmission, telecommunications, railway construction and utility projects.
Suitable for the construction and maintenance of transmission and distribution lines.
Product Details
With its features bellow, this portable MARSHINE Model DJ Electric Winch can helps boost efficiency, safety, and productivity on the job site.
Trusted Manufacturer: MARSHINE is a world-renowned brand of transmission line construction tools.
Engineering Excellence: Precision manufacturing and strict quality control ensure reliable performance on every job.
Versatile Models: The DJ Series offers a variety of capacity options to meet a variety of operational needs.
Competitive Pricing: Provides high-value solutions that balance cost and performance.
Superior Reliability: With decades of engineering expertise, MARSHINE is trusted by professionals around the world.
Energy Efficiency: Optimized motor design reduces power consumption while maintaining optimal performance.
