DSM Dyneema Fibre Rope

Model:18170A
Manufactured by MARSHINE, who was a large Chinese manufacturer using ultra-high molecular weight polyethylene (UHMWPE) fibers, this MARSHINE DSM Dyneema Fiber Rope we supplied in competitive price. It combines high tensile strength, lower stretch, and lightweight structure, can make it a reliable choice for electric construction teams.

This MARSHINE DSM Dyneema Fibre Rope is engineered with ultra-high-molecular-weight polyethylene (UHMWPE), its performs is outstanding than the traditional steel wires, can offering a better strength-to-weight ratio.


Product Parameter

Item number Diameter(mm) Linear density(g/m) After diameter(mm) After linear density(g/m) Break force(KN)
18170A 2 2.31 3 3.2 4.3
18170B 3 4.65 4.5 7.3 8.5
18170C 3.5 6.78 5 9.5 11.4
18170D 4 9.31 5.5 13 16.6
18170E 4.5 11.3 6 16 19
18170F 5 14 7 20 24.4
18170G 6 20 8 28.2 31.9
18Ô170H 7 27 9 36 43.6
18170J 8 35 10 48.4 58.8
18170K 9 42 11 58.5 70.3
18170L 10 56 12 77 92.5
18170M 11 70 13 97 115
18170N 12 84 14 113.4 137
18170P 13 98 15 132 159
18170Q 14 106 16 150 180
18170R 16 132 18 177 211
18170S 18 186 21 247.3 296

Product Feature

The MARSHINE DSM Dyneema Fiber Rope is 10 times stronger than steel wire rope of the same diameter, but significantly lighter. Designed for use in hard outdoor environments, it owns minimal stretching under load, can ensures the precise control and tensioning. And with the smooth surface and soft texture, this rope can effectively reduce the risk of injury and improve the operational efficiency. It owns the maintains performance, can function well even when exposed to moisture, oil, and chemicals. Compared to steel wire ropes, this rope can improve the safety of power line operations.

Product Application

The MARSHINE DSM Dyneema Fiber Rope is ideal for pulling and stringing of the conductors and OPGW cables in the transmission line construction. Furthermore, this rope can be a good choice for the maintenance and installation of utility and telecommunication infrastructure, offshore and rescue operations where lightweight, high-strength ropes are required, or forestry and heavy lifting operations, synthetic ropes are preferred over metal wires.

Product Details

The MARSHINE DSM Dyneema Fibre Rope offers an advanced, lightweight, and durable alternative to conventional steel wire ropes, here are the details about it:


Reliable quality: MARSHINE uses premium Dyneema® fibers and rigorous quality control.


Field-proven durability: Trusted by linemen and technicians in all terrains and weather conditions.


Globally recognized: MARSHINE tools and accessories are used on major projects in more than 50 countries.


Trusted worldwide: Trusted by engineers, marine engineers and industry leaders around the world.
