As a cable pulling winch machine that can offer the operator with the precision, durability, and the versatility, this MARSHINE 3 Ton Wire Rope Winch Machine is been engineered to deal with the remote area cable handling tasks in the construction, utilities, and renewable energy industries. Designed for electricians and linemen who demands the reliability under the heavy loads, this winch is able to deliver the outstanding performance in the demanding environments.
Product Parameter
| Item number | 09151 | 09152 | |
| Model | JJCS-30 | JJQS-30 | |
| Engine | Model | R175A Diesel Engine | GX270 Gasoline Engine |
| Power(hp) | 6 | 9 | |
| Speed(rpm) | 2600 | 3600 | |
| Pull force (kn)/Speed(m/min) | Slow | 30/5.7 | 30/7.43 |
| Moderate | 18.9/9.1 | 19.2/11.8 | |
| Quick | 7.6/22.7 | 7.2/31.4 | |
| Reverse | -/6.5 | -/8.4 | |
| Drum bottom of groove diameter(mm) | Φ230 | Φ230 | |
| Dimension(mm) | 1000*670*600 | 1000*670*600 | |
| Weight(kg) | 305 | 270 | |
Product Feature
Been built from the high-tensile steel to handle the tough constructions,and with the 3 ton hydraulic power, this MARSHINE 3 Ton Wire Rope Winch Machine is able to handle the heavy-duty cable pulling, lifting, and tensioning tasks with ease from the utility line installations to the marine mooring operations. Its advanced drum design can ensures the even wire rope spooling while reducing the tangling or kinking during the operations. And with the automatic braking system, this winch machine can be used to prevents the accidental slippage and ensures the load stability during the operations. And with its lightweight yet compact design, this winch can be transport to the construction site with ease, is able to improve the construction efficiency.
Product Application
The MARSHINE 3 Ton Wire Rope Winch Machine is a versatile device that suitable for installing the overhead transmission lines, underground cables, and for the substation wiring tasks. And it is perfect for deploying the fiber-optic cables in the urban or the rural networks in the telecom constructions, or for anchoring the wind turbine cables or tensioning the solar farm wiring tasks. In addition, it is able to secure the vessels, sub-sea cables, or the floating platforms as well.
Product Details
The 3 Ton Rope Winch Wire Rope Winches is our MARSHINE outstanding works for the cable installation constructions, is a reliable choice for the electricians and linemen who requires the efficiency and stable performance.
Material: Alloy Steel.
Feature: Explosion-Proof.
Leading Time:30-35days.
Certification: CE, ISO.
Transport Package: Carton Box.
Warranty:1year.
Origin: China.
