MARSHINE introduces its 3 Ton Rope Winch Wire Rope Winches — a powerhouse of precision, durability, and versatility engineered to tackle the toughest cable handling tasks in construction, utilities, renewable energy, and marine industries. Designed for professionals who demand reliability under heavy loads, this winch combines cutting-edge engineering with user-centric features to deliver unmatched performance in demanding environments.
| Item number | 09151 | 09152 | |
| Model | JJCS-30 | JJQS-30 | |
| Engine | Model | R175A Diesel Engine | GX270 Gasoline Engine |
| Power(hp) | 6 | 9 | |
| Speed(rpm) | 2600 | 3600 | |
| Pull force (kn)/Speed(m/min) | Slow | 30/5.7 | 30/7.43 |
| Moderate | 18.9/9.1 | 19.2/11.8 | |
| Quick | 7.6/22.7 | 7.2/31.4 | |
| Reverse | -/6.5 | -/8.4 | |
| Drum bottom of groove diameter(mm) | Φ230 | Φ230 | |
| Dimension(mm) | 1000*670*600 | 1000*670*600 | |
| Weight(kg) | 305 | 270 | |
Robust Load Capacity:
3-Ton Capacity: Effortlessly handles heavy-duty cable pulling, lifting, and tensioning tasks, from utility line installations to marine mooring operations.
High-Tensile Steel Construction: This wire rope winch was been built to withstand extreme stress, corrosion, and wear, ensuring longevity in harsh conditions.
Smooth & Precise Operation:
Advanced Drum Design: Ensures even wire rope spooling and minimizes tangling or kinking during operation.
Safety-First Engineering:
Automatic Braking System: This wire rope winch can be used to prevents accidental slippage and ensures load stability during operation.
Overload Protection: Built-in sensors halt operation if the load exceeds capacity, safeguarding both equipment and operators.
Portable for construction:
Compact Design: Lightweight and easy to transport, ideal for remote job sites or confined spaces.
The MARSHINE 3 Ton Rope Winch Wire Rope Winches is a versatile solution for rope stringing, bellow is the applicable situation for our rope winch:
Utility & Power Grids: Install overhead transmission lines, underground cables, or substation wiring.
Telecommunications: Deploy fiber optic cables in urban or rural networks.
Renewable Energy: Anchor wind turbine cables or tension solar farm wiring.
Marine & Offshore: Secure vessels, sub-sea cables, or floating platforms.
Construction & Mining: Lift heavy materials or equipment in rugged terrains.
The 3 Ton Rope Winch Wire Rope Winches is our MARSHINE's outstanding works for cable installation constructions, bellow is it's details:
Material: Steel;
Feature: Explosion-Proof;
Certification: CE, ISO;
Transport Package: Carton Box;
Origin: China;
