Designed for the fast cable and conductor stringing, this MARSHINE ZZC350 Self-Moving Traction Machine was a powerful yet efficient equipment which features a self-propelled design, and combined with the reliable pulling performance and the excellent maneuverability, is able to help the operators deal with the long term cable stringing works in the power line constructions, utility works, and the other long-distance cable installation projects. Been built with the powerful gasoline engine and the robust frame, this machine can ensures the high productivity and the last long durability in the demanding field conditions while protecting the user's personal safety.
Product Parameter
| Model | ZZC350 |
| block passed Diameter range(mm) | φ9-φ26 |
| Maximum Creeping Angle (°) | 31° |
| Gasoline Dynamo Type | YK950/650W |
| Driving Dynamo Type | 100YYJ140-3 (140W) |
| Remote Control Linear Distance (m) | 300-500m |
| Dimensions (mm) | 447*488*763 |
| Running Speed (m/min) | 17 |
| Horizontal Pull (N) | 350 |
| Weight (kg) | 46.5 |
Product Feature
As it is been manufactured with the self-propelled design, this MARSHINE ZZC350 Self-Moving Traction Machine is able to provide the users with easy movement on the construction site, and can reposition it without the additional towing equipment. And with its long traction distance that up to 300 to 500m, this machine is able to help the users to deal with the long-distance cable or the conductor stringing operations. And with its durable constructions that been built with the high-strength alloy steel, with the protective oil-paint coating, it is able to withstand the harsh construction conditions during the cable stringing operations. With its simple control system, this equipment can ensures the smooth handling and allows the users to adjust the traction precisely. Its low maintenance require is also a attractive point for the utility workers and the electricians.
Product Application
This MARSHINE ZZC350 Self-Moving Traction Machine is perfect for the overhead transmission line stringing projects, and can be used to deal with the power distribution and the utility cable installation tasks, or for the long-distance conductor pulling and guiding operations. In addition, it is suitable for the heavy-duty cable laying tasks in the industrial or the infrastructure projects, and the field works that requires for mobile traction equipment as well.
Product Details
This MARSHINE ZZC350 Self-Moving Traction Machine is a reliable, efficient, and durable traction equipment for the utility electricians and workers who requires for a good partner for the cable and conductor stringing operations.
Original Country:China.
Lead Time:10-12days.
Warranty:1year.
Certifications:ISO9001,CE.
