Manual 600-3200lbs Wire Rope Winches

Being a large-scale company trading for Manual 600-3200lbs Wire Rope Winches with good price from China, MARSHINE can continuously manufacture and supply the international standard products to meeting the customer’s needs, our gasoline powered winch, electric powered winch was great for the construction too. MARSHINE hope we can be the best choice for more customers.

Send Inquiry

Product Description

As a manual tool with automatic brake, MARSHINE Manual 600-3200lbs Wire Rope Winches, it's mechanical function is to manually pull the cargo by the rotation of the winch drum. The wire rope drum is driven by gears and effectively pulls the cargo by rotating the wire rope or braided belt wound on it. Equipped with an automatic brake device, it automatically opens the brake when the winch drum remains stationary while the wire rope is pulling the cargo to ensure safe operation. This feature enhances safety and reliability during operation.

Product Parameter

Item num	Model	Material Gear thickness	Hook Forge (g)	Surface	Wire rope (7*19)	Gear Ratio	Per box G/ W (kg)	Qty / CTN (PCS)	Per box G/ W (kg)
09211	JL600LBS	Q235, 5mm	140	Galvanizing / Electrophoresis	φ4.0mm*6m	3.1:1	2.5	6	15
09212	JL800LBS	Q235, 5mm	140		φ4.0mm*7m	3.1:1	2.6	6	15.5
09213	JL1000LBS	Q235, 6mm	140		φ4.5mm*8m	4.1:1	3.3	6	20
09214	JL1200LBS	Q235, 6mm	140		φ4.5mm*10m	4.1:1	3.5	6	21
09215	JL1400LBS	Q235, 8mm	160		φ4.5mm*10m	4.1:1	3.6	6	22
09216	JL1600LBS	Q235, 8mm	160		φ4.5mm*10m	4.1:1	3.8	6	23
09217	JL1800LBS	Q235, 8mm	160		Φ5.0mm*8m	4.1:1	4.3	6	26
09218	JL2000LBS	Q235, 8mm	180		Φ5.0mm*10m	4.1:1	4.5	6	27
09219	JL2500LBS	Q235, 8mm	230		Φ5.0mm*10m	4.1:1& 8.1/1	5.7	4	23
09219A	JL3000LBS	Q235, 8mm	230		Φ5.5mm*10m	4.1:1& 8.1/1	6	4	24
09219B	JL3200LBS	Q235, 8mm	230		Φ6.0mm*10m	4.1:1& 8.1/1	6	4	24.5

Product Feature

Manual winches are essential tools used in various industries and applications where pulling or lifting heavy loads is required. Here are some key features of manual winches:

Mechanical Advantage

Gear System: Manual winches typically employ a gear system that provides mechanical advantage, making it easier to pull heavy loads with less effort.

Ratchets: Many manual winches include ratchets that allow the user to pause and secure the load at any point during the pulling process.

Durability and Strength

High-Strength Materials: Constructed from durable materials like steel or reinforced alloys, manual winches are designed to withstand heavy loads and harsh conditions.

Load Capacity: Available in various load capacities, manual winches can handle weights ranging from a few hundred pounds to several tons, depending on the model.

Portability

Compact Design: Many manual winches are designed to be compact and lightweight, making them easy to transport and use in different locations.

Mounting Options: They often come with mounting brackets or hooks, allowing for easy attachment to vehicles, frames, or other structures.

Ease of Use

Simple Operation: Manual winches are typically operated using a crank or lever, which requires minimal training to use effectively.

Safety Features: Some models include safety features such as automatic locking mechanisms and overload protection to prevent accidents and equipment damage.

Versatility

Multiple Applications: Manual winches can be used in a variety of settings, including construction sites, farms, workshops, and outdoor recreational activities.

Compatibility: They can be paired with different types of ropes or cables, including wire rope, synthetic rope, and chain, to suit specific needs.

Maintenance

Low Maintenance: Manual winches generally require minimal maintenance, with occasional lubrication and inspection of parts to ensure smooth operation.

Replaceable Parts: Many components, such as gears and handles, are replaceable, extending the life of the winch.

Cost-Effective

Affordable: Compared to motorized winches, manual winches are often more affordable, making them a cost-effective solution for many applications.

No Power Source Required: Since they operate manually, there is no need for an external power source, which can be advantageous in remote or off-grid locations.

Product Application

Automotive Industry

Towing and Recovery: Manual winches are commonly used for towing vehicles, extracting stuck cars, or moving heavy automotive parts.

Truck and Trailer Loading: They assist in loading and unloading heavy cargo onto trucks and trailers, ensuring safe and efficient handling.

Marine Industry

Boat Handling: Manual winches are used on boats for tasks such as raising and lowering sails, anchoring, and handling fishing nets.

Docking and Mooring: They help in securing boats to docks or mooring points, ensuring stability and preventing movement due to water currents.

Construction and Civil Engineering

Material Handling: On construction sites, manual winches are used to lift and move heavy building materials, such as concrete blocks, steel beams, and lumber.

Tensioning and Rigging: They assist in tensioning cables and rigging equipment, which is crucial for setting up scaffolding, cranes, and other temporary structures.

Forestry and Agriculture

Tree Felling and Log Extraction: Manual winches help in safely felling trees and dragging logs out of forests, reducing the physical strain on workers.

Farm Equipment Movement: They are used to move heavy farm machinery, such as tractors and combines, or to lift and position large hay bales.

Mining and Quarrying

Material Extraction: In mining operations, manual winches assist in extracting ore and other materials from mineshafts or quarries.

Equipment Positioning: They help in positioning heavy mining equipment and machinery, ensuring precise placement and operation.

Outdoor Recreation and Adventure

Camping and Off-Roading: Enthusiasts use manual winches for tasks such as securing tents, pulling vehicles out of mud or snow, and setting up zip lines.

Rock Climbing and Mountaineering: They are used for setting up anchors, hauling gear, and rescuing climbers in emergency situations.

Industrial Maintenance and Repair

Heavy Equipment Maintenance: Manual winches assist in lifting and moving heavy components during maintenance and repair of industrial machinery.

Facility Upkeep: They are used in facilities for tasks such as moving large storage containers, installing heavy equipment, and performing structural repairs.
